Advance Technology Handheld Induction Heating Equipment for 5m Flexible Connection Hf-40kw

MOQ:	1
harga:	1800

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Model TIDAK.:

HF-40KW

Struktur:

Tipe Vertikal

Merek:

ORD

Kekuatan:

40KW

Frekuensi:

30-80khz

Aplikasi Kerja:

Pemanasan, Penempaan, Pendinginan, Peleburan, Anil

Panjang kabel:

Koneksi Fleksibel 5m+2m

Kekuatan kerja:

3*380V/415V/440V/480V 50-60Hz

Kisaran tegangan operasi:

340-430V AC

masukan arus:

40A

Prinsip:

Pemanasan Induksi

Inti:

IGBT

Gaya:

Mesin Pemanas Induksi

Paket Transportasi:

KOTAK KAYU

Spesifikasi:

CE, SGS, ISO

Merek dagang:

ORD

Asal:

Cina

Kode HS:

8514400090

Kapasitas Produksi:

10.000 set

Menyoroti:

handheld induction heating equipment 5m flexible

HF-40KW induction heater handheld

high frequency induction heater with warranty

Deskripsi Produk

Energy conservation hand type induction heating machine for welding heattreatment ,forging quenching ,full boiling

Advantage:
1 More than 17 years experience,stable and goods performance
2 CE certificated
3 Copperated with CHOW TAI FOOKS, Matsushita,Foxconn, Media, Gree and ZHIGAO Air conditioner.
4 Suitable for a large range, heating, quenching, forging, melting, solding and so on.
5 2 Transformer ratios more options connect induction coil
6 Coaxial Connection Flexible, can handle the flexible to work the workpiece that normal coil can not get it.
Main characteristics:

1 Siemens IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost.
2 100% Duty cycle, continuous working is allowed at maximum power output.
3 Display of heating power and heating current and oscillating frequency;
4 Simple to install, Installation can be done by unprofessional person very easily;
5 Light weight
7 Advantages of the model with timer: The power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability;

Advance Technology Handheld Induction Heating Equipment for 5m Flexible Connection Hf-40kw 1

Packing Photos:

Advance Technology Handheld Induction Heating Equipment for 5m Flexible Connection Hf-40kw 3

Type	HF-40KW
Work Power	3*380v/415v/440v/480v 50-60hz
The range of operating voltage	340-430V AC
Output power	40KW
Input current	40A
Fluctuating frequency	30-80khz
Timing (Heat time,Retain time,Cool time)	1-99S
The flow rate of cooling water	0.15 Mpa 9L/Min
Water temperature protection point	40centidegree
Duty cycle	100% (40degree room temperature)
Weight	Mainparts:32Kg+28KG
Size	Main Parts:560230480mm Transfromer Part: 460265440MM

Pre-sale service:
1. recommend the most suitable machine for customers, according to their requirements.
2. Inquiry and consulting support.
3. Sample testing support.
4. View our Factory.

In-sale service:
1. Strictly manufacture the machine, according to relevant technical standards.
2. Take run test, according to relevant equipment test run regulations.
3. Strictly check up the machine, before delivery
4. Delivery on time.

After-sale service:
1. Warranty time: Within 18 months from the date of delivering, 12months from date of receiving.
2. Within warranty all parts are free for customer, any fault caused by non-artificial reason, any quality problems such as design, manufacture, or procedure occurs, We shall provide replacement parts after detecting the faults.
3. If any big quality problems occurs out of the guarantee period, we will send maintenance
technician to provide visiting service after checking with the customer and charge for a favorable price.
5. We will provide a lifetime cost price to the buyer with the materials and spare parts used in system operation, equipment maintenance.
6. The above mentioned are only basic aftersale service requirements,we will make more promises related to quality assurance and operation guarantee.
